The UR35-L00AU-W-G-P is an industrial 4G LTE cellular router with 5-port Ethernet (4x PoE), WiFi, GNSS, and terminal block interfaces. Featuring a comprehensive suite of Layer-3 and Layer-4 network protocols, UR35 provides secure and reliable solutions for a range of industrial telematics and M2M deployments. Supports all Australian 3G/4G bands including B28 700 MHz.

FEATURES:

• Rugged Enclosure with a wide operation range from -40 to 70°C
• Dual SIM redundancy
• 1x Terminal Block for RS232/RS485/IO
• 4x LAN Ethernet Ports, 1x WAN Ethernet Port
• 4x PoE 802.3at/af Ethernet Ports
• GPS Antenna connection
• Supports WiFi Client and AP Mode
• Open VPN/IPsec/PPTP/L2TP/DMVPN/GRE

  UR35 is a highly economic 4G modem which has a featureset tailored for industrial communications. It uses a standard Cat-4 LTE chipset which supports data speeds up to 150 Mb/s (20 to 30 Mb/s typical). The UR35-L00AU-W-G-P version has 5x 10/100 Ethernet ports, four of which are LAN supporting PoE output (802.3at/af) when powered with a 48 Vdc supply. UR35 is designed for industrial communications with a Terminal Block supporting RS232/RS485/IO, GNSS (GPS) tracking, and the usual set of L3/L4 network protocols.

  The W-G-P model of UR35 has two SMA connectors for external 4G MIMO antennas, one SMA connector for GNSS (GPS), and a single SMA connector for operation as a WiFi Access Point or Client.
